Product Introduction
NVIDIA Jetson Orin Nano Product Specifications
Motherboard：Jetson AGX Orin 32GB/Jetson AGX Orin 64GB (Official Kit)
AI Performance：275 TOPS
GPU：NVIDIA Ampere architecture with 2048 NVIDlA CUDA cores and 64 Tensor Cores
CPU：12-core Arm Cortex -A78AE v8.2 64-bit CPU 3MB L2 + 6MB L3
Deep Learning Accelerator：2× NVDLA v2.0
Visual Accelerator：PVA v2.0
Memory：32GB 256-bit LPDDR5 204.8 GB/S，64GB 256-bit LPDDR5 204.8 GB/S
Storage：64GB eMMC 5.1
Video Coding：2× 4K60 | 4× 4K30 | 8× 1080p60 | 16× 1080p30 (H.265)
Video Decoding：1× 8K30 | 2× 4K60 | 6× 4K30 | 12× 1080p60 | 24× 1080p30(H.265)
Camera：16 lane MlPl CSl-2 connector
PCle：Standard PCle ×l6 connector with ×8 PCle Gen4
RJ45：Up to 10 GbE
M.2 Key M：×4 PCle Gen 4
M.2 Key E：×1 PCle Gen 4,
USB 2.0,UART,I2S USB Type-C：2× USB 3.2 Gen2
USB Type-A：4× USB 3.2 Gen2
USB Micro-B：DisplayPort 1.4a (+MST)
Display Port：UHS-1 cards up to SDR104 mode
microSD slot：40-pin header (12C,GPIO, SPI, CAN,I2S, UART, DMIC)
other：40-pin header(12C,GPIO, SPI, CAN,I2S, UART, DMIC)，12-pin automation header，10-pin audio panel header，10-pin JTAG header，4-pin fan header，2-pin RTC battery backup connector，DC power jack，Power, Force Recovery, and Reset buttons
Power：15W-60W
Size：110mm× 110mm× 71.65mm
Product details
